This item is sold by
الوصف
Specifications
| Performance Parameters | |
| Image sensor | CMOS |
| Image size | 648 x 488 pixels |
| Light source | Red light, LED |
| Precision | 5mi |
| Depth of scan field | 6-25cm (code 39, 15mil), 6-25cm (UPC/EAN, 15mil) 4mil/0.1mm at pieces 90%, code 39 |
| Sensitivity | Roll : 360° Skew : ±65° Pitch : ±60° |
| Support interface | USB and RS232 ±30° |
| Print contrast signal | 30% |
| Indicator | Buzzer, LED |
| Scan mode | Manual and automatic and continuous |
| Supports interface | USB-HID, USB-virtual COM and RS232 |
| Print contrast | 20% UPC/EAN 100% |
| Mention pattern | Buzzer, indicator |
| Scan mode | Manual and automatic and continuous |
| Mechanical Parameters | |
| Dimension | 171mm x 66mm x 86mm170 x 68 x 98mm |
| Weight | 130g |
| Materials | ABS + PC |
| Cable | Standard 2m straight |
| Electrical Parameters | |
| Voltage | 3.3V DC ±5% |
| Operating current | 135mA |
| Static current | 60mA |
| Light source | 625nm |
| EMC | CE and FCC, DOC compliance |
| Environment Parameters | |
| Operating temperature | 20 to 60°C |
| Storage temperature | -20 to 60°C |
| Humidity | 5 to 95% relative humidity, non-condensing |
| Light levels | Daylight, 0-100,000lux |
| Shock | Designed to withstand 1.5m drops |
| IP class | IP54 |
| Decode Capability | |
| 1D : EAN-8, EAN-13, UPC-A,UPC-E, code 39, code 93, code 128, EAN128, codabar, industrial 2of 5, Interleave 2of5, Matrix 2 of 5, MSI, Chinese postcode 2D : PDF417, QR code (mode/2), DataMatrix (ECC200, ECC000, 050, 080, 100, 140) |
