Description
Features
- Fast Dual-Band Wi-Fi : Simultaneous 450 Mbps On 2.4 GHz And 867 Mbps On 5 GHz Totals 1317 Mbps Wi-Fi Speeds.
- Integrated Into Omada SDN : Zero-Touch Provisioning (ZTP), Centralized Cloud Management, And Intelligent Monitoring.
- Centralized Management : Cloud Access And Omada App For Ultra Convenience And Easy Management.
- Seamless Roaming : Even Video Streams And Voice Calls Are Unaffected As Users Move Between Locations.
- PoE Support : Support Both Standard 802.3af/at And Passive PoE (PoE Adapter Is Not Included) For Flexible Installations.
- Secure Guest Network : Along With Multiple Authentication Options (SMS/Facebook Wi-Fi/ Voucher, etc.) And Abundant Wireless Security Technologies.
- Advanced Wireless Tech : Optimize Network Performance Eith MU-MIMO, Band Steering, Airtime Fairness And Beamforming Technologies.
Specifications
| Hardware Features | |
| Interface | Gigabit Ethernet (RJ-45) Port × 1 (Support IEEE802.3af/at PoE And Passive PoE) |
| Physical Security Lock | Yes |
| Button | Reset |
| Power Supply | 802.3af/at PoE 48V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Is Not Included) |
| Power Consumption | EU: 9.7W US: 12.1W |
| Dimensions ( W x D x H ) | 8.1 × 7.1 × 1.5 in (205.5 × 181.5 × 37.1 mm) |
| Antenna Type | 3 Internal Omni 2.4 GHz: 4 dBi 5 GHz: 5 dBi |
| Mounting | Ceiling /Wall Mounting (Kits Included) |
| Wireless Features | |
| Wireless Standards | IEEE 802.11ac/n/g/b/a |
| Frequency | 2.4 GHz & 5 GHz |
| Signal Rate | 5 GHz : Up To 867 Mbps 2.4 GHz : Up To 450 Mbps |
| Wireless Functions | Multiple SSIDs (Up To 15 SSIDs, 8 For 2.4GHz Band, 7 For 5GHz Band) Enable/Disable Wireless Radio Automatic Channel Assignment Transmit Power Control (Adjust Transmit Power On dBm) QoS(WMM) Seamless Roaming Omada Mesh Band Steering Load Balance MU-MIMO Airtime Fairness Beamforming Rate Limit Reboot Schedule Wireless Schedule Wireless Statistics Based On SSID/AP/Client |
| Wireless Security | Captive Portal Authentication Access Control Wireless Mac Address Filtering Wireless Isolation Between Clients SSID To VLAN Mapping Rogue AP Detection 802.1X Support |
| Transmission Power | CE : ≤20 dBm(2.4 GHz, EIRP) ≤23 dBm(5 GHz, EIRP) FCC : ≤24 dBm(2.4 GHz) ≤22 dBm(5 GHz) |
| Management | |
| Omada App | Yes |
| Centralized Management | Omada Hardware Controller OC300 Omada Hardware Controller OC200 Omada Software Controller Omada Cloud-Based Controller |
| Cloud Access | Yes, Through OC300 OC200 Omada Software Controller Omada Cloud-Based Controller |
| Email Alerts | Yes |
| LED ON/OFF Control | Yes |
| Management MAC Access Control | Yes |
| SNMP | v1,v2c |
| System Logging Local/Remote Syslog | Local/Remote Syslog |
| SSH | Yes |
| Web-Based Management | HTTP/HTTPS |
| L3 Management | Yes |
| Multi-Site Management | Yes |
| Management VLAN | Yes |
| Zero-Touch Provisioning | Yes. Requiring The Use Of Omada Cloud-Based Controller |
| Others | |
| Certification | CE, FCC, RoHS |
| Package Contents | AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP223 Mounting Kits Installation Guide |
| System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux |
| Environment | Operating Temperature : 0–40 ℃ (32–104 ℉) Storage Temperature : -40–70 ℃ (-40–158 ℉) Operating Humidity : 10–90% RH Non-Condensing Storage Humidity : 5–90% RH Non-Condensing |
What In The Box
- 1 x TP-Link Omada EAP223 AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point 802.11 ac WAVE 2
- 1 x Mounting Kits
- 1 x Installation Guide
Warranty
3 Year Warranty
Local Manufacturer Warranty
