D-Link 16 Ports Gigabit Unmanaged Switch (DGS-1016C)

16-Port Gigabit Unmanaged Switch

DGS-1016C

Economical, plug-and-play networking switch solution for SOHO and small and medium businesses.

16 Gigabit LAN ports for high-speed wired connections

Plug-and-play installation for convenience

Auto-negotation on all ports

Half/full-duplex, auto MDI/MDIX, and store-and-forward switching

Full wire-speed data transmission

Energy-efficient design

Specifications

1000Base-T Interface 16

Auto MDI/MDIX   Yes

Switching Capacity   32Gbps

Max. Packet Forwarding Rate   23.808 Mpps

Dimension    282.2 x 178 x 44.5 mm (11.11 in. x 7.01 in. x 1.75 in.)

Weight     1.06 kg

Operation Temperature    0 ~ 40 °C

Storage Temperature    - 40 ~ 70 °C

Operation Humidity   10% ~ 90% RH

Storage Humidity         5% ~ 95% RH

Maximum Power Consumption 9.3 watts

Standby Power Consumption 4.48 watts

Maximum Heat Dissipation     33.554 BTU/h

Acoustic 0 dB

MTBF 208,124 hours

Power Input   AC 100V-240V

Packet Buffer Size    256KBytes

FAN Fanless

Comply with RoHS 6  Yes

3Energy Efficiency Ethernet (EEE) Yes

Power Saving By Link Status Yes

Power Saving By Cable Length Yes

MAC Address Table Size 8000 802.3x Flow Control Yes

Head-of-line (HOL) Blocking Prevention   Yes

Jumbo Frame 9,216 Bytes

Package Contents : (DGS-1016C)

1 x 16 port Gigabite Switch

1 x 12V/1A External Adapter

4 x Rubber Feet

1 x Wall Mounting Kit

1 x Quick Install Guide
