Cooler Master Platinum Full Modular 80 PLUS Power Supply (XG750)

Cooler Master Platinum Full Modular 80 PLUS Power Supply (XG750)

Mode
lMPG-7501-AFBAP-UK
ATX Version
Intel ATX
12V Ver. 2.53
PFC
Active PFC
Input Voltage
100-240V
Input Current
10-5A
Input Frequency
 50-60Hz
Dimensions (L x W x H) 160 x 150 x 86 mm Fan Size
135mm
 Fan Speed
1800 RPM
 Noise Level @ 100% ? 25 dBA Efficiency ? 92% @ Typical Load
80 PLUS Rating
 80 PLUS Platinum
 ErP 2014 Lot 3
Yes
Operating Temperature
0-50°C
Power Good Signal
 100 - 150 ms
Hold Up Time ?
20ms
 MTBF >100,000 Hours Protections OPP, OVP, OCP, UVP, SCP, OTP, Surge and Inrush Protection
Regulatory
TUV, cTUVus, CE, BSMI, FCC, CCC, EAC, UKCA
ATX 24 Pin Connectors 1
EPS 4+4 Pin Connectors 1
EPS 8 Pin Connector 1
SATA Connectors 12
Peripheral 4
Pin Connectors 4
PCI-e 6+2 Pin Connectors 4
Series XG Series
80 Plus Platinum
Modular Full Modular
Wattage 500 to 750W
