TP-Link AC1300 Wireless Dual Band USB Adapter Archer T4U

HARDWARE FEATURES

Interface    USB 3.0

Button     WPS button

Dimensions    ( W x D x H ) 3.64×1.24×0.55 in.

(92.47×31.55×13.9mm)

Antenna 2 High Gain External Antennas

Antenna Type   Omni Directional

WIRELESS FEATURES

Wireless Standards   IEEE 802.11ac, IEEE 802.11a,

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Frequency  5GHz

2.4GHz

Signal Rate  5GHz

11ac: Up to 867Mbps(dynamic)

11n: Up to 300Mbps(dynamic)

11a: Up to 54Mbps(dynamic)

2.4GHz

11n: Up to 400Mbps(dynamic)

11g: Up to 54Mbps(dynamic)

11b: Up to 11Mbps(dynamic)

Reception Sensitivity 5GHz:

11a 6Mbps: -91dBm

11a 54Mbps: -77dBm

11nHT20?-74dBm

11nHT40?-71dBm

11ac HT20: -70dBm

11ac HT40: -66dBm

11ac HT80: -62dBm

2.4GHz:

11b 11Mbps: -86dBm

11g 54Mbps: -74dBm

11n HT20: -72dBm

11n HT40: -70dBm

Transmit Power 20dBm (EIRP)

Wireless Modes Ad-Hoc / Infrastructure mode

Wireless Security Support 64/128 bit WEP, WPA-PSK/WPA2-PSK

Modulation Technology DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM, 256-QAM

OTHERS

Certification CE, FCC, RoHS

Package Contents   AC1300 High Gain Wireless MU-MIMO USB Adapter Archer T4U

Quick Installation Guide

Resource CD

System Requirements Windows 10/8.1/8/7/XP, Mac OS X 10.9-10.13

Environment Operating Temperature: 0℃~40℃ (32℉~104℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
