Tenda Ap5 300Mbps Wireless N High Power Access Point

product details of TENDA AP5 300MBPS WIRELESS N HIGH POWER ACCESS POINT

OVERVIEW :

AP5 is designed to boost the range of your existing WiFi and creates a stronger signal for game consoles, printers, smart phone, tablet. Power over ethernet supported and wall-mount design make it flexible to deploy in any location. It has multi operation modes like Universal Repeater, Clien(Station), WISP, which can adapt various application scenarios. It is an ideal Wi-Fi booster for large houses, villas, eatery, large stores etc.

SPECIFICATIONS :

Dimension148*146.2*31.5mm

Standard&ProtocolIEEE 802.11n/g/b

Interface2 * 10/100M Ethernet Port (RJ45)

Antenna3*5dBi Detachable Omni Directional (RP-SMA)

Button1*Reset

1*Range Extender

Power MethodDC 12V=1A Passive PoE

Passive PoE power supplyUp to 40 meters Passive PoE is supported(cat5e or up)

Reception Sensitivityb mode： 1M -89dBm@8%

11M -87dBm@8% PER

g mode： 54M -74dBm@8% PER； n mode： 72.2M -74dBm@8% PER

150M -72dBm@8% PER

LEDSYS,WPS,Bridge,WiFi,LAN1,LAN2

Hardware DeploymentDesktop/Wall Mount

Frequency Range2.4GHz-2.483GHz

LAN SettingsStatic IP

Dynamic IP

DHCP ServerDHCP Server

Clients list

Wireless Rate11n: Up to 300Mbps(dynamic)

11g: Up to 54Mbps(dynamic)

11b: Up to 11Mbps(dynamic)

Operating ModeAccess Point

Universal Repeater

Station(Client)

WISP (Client+Router)

Client+AP

Wireless Function8 SSID

Enable/Disable Wireless Radio

Broadcast SSID

SSID Hidden automatically when exceed client limit

Client limit for SSID

Transmission output power

AP isolation

RSSI threshold for wireless clients

WMM capable

APSD capable

Access control based mac address

Wireless Client list

VLAN for multi SSID

Wrieless Security64/128 WEP

WPA-PSK

WPA2-PSK

WPA&WPA2-PSK

WPA

WPA2

Video user capacity5

wireless users capacity20+

DiagosticWireless site survey

Ping

Traceroute

Network ServiceSchedule Reboot

Http/Https

Managed by ACAC500

Package Content300Mbps Wireless N High Power Access Point AP5

1*PoE Injector

1*Quick Installation Guide

1*Ethernet cable

1*Power Adapter

2*Screws

2*Plastic Bolt

Management ToolReboot

Restore to factory default

System Log

Firmware update

Time&Date Setting

Backup/Restore Configuration

Username Managerment

TemperatureOperating Temperature:-10℃~45℃

Storage Temperature:    -30℃~70℃

HumidityOperating Humidity:10%~90% non-condensing

Storage Humidity:5%~90% non-condensing

Default SettingsIP Address: 192.168.0.254

Login Username:admin

Login Password:admin

CertificationFCC/CE/Rohs/VoC.
