Description
Product Introduction
10/100M Unmanaged PoE Switch Can Provide Both 10/100M Ethernet Data And Power Over Network Cable, It Can Be Used As Ethernet Power Sourching Equipment, It Can Automatically Detect And Idetify Whether Connected Devices Such As IP Camera Comply With Standard IEEE PoE 802.3Aat And Supply Power For Them. 10.1ooM Unmanaged PoE Switch Easier The Develoyment Of Wireless AP, IP Camerea And IP - Based Network Equipment.
Specifications
| Product Name | 5-Port AF PoE Switch With 4 PoE Ports And 1 Uplink |
| Model | POE31004P |
| Connector | 5x 10/100M Copper Cable RJ45 Ports(all Ports Support MDI/MDIX) 4x PoE Ports |
| Network Media | 10BASE-T : Cat3,4,5 UTP(≤100 meter) 100BASE-TX : Cat5 Or More UTP (≤100 meter) |
| Bandwidth | 1.6Gbps (non-blocking) |
| Address Database Size | 1K |
| MTBF | 100,000 hours |
| Network Latency | Maximum Delay Less Than 20 Microseconds |
| Forwarding Mode | Store-And-Forward |
| Buffer Memory | 768KB |
| Network Protocols |
IEEE 802.3i 10BASET IEEE 802.3u 100BASETX IEEE 802.3x Flow Control IEEE 802.3af DTE Power via MDI IEEE 802.3af/at
|
| LED Display | System : Power Supply Every Port : connecting, PoE Working Status |
| PoE Ports | 4* PoE Ports |
| PoE Port Power | Max 30W |
| PoE Standard | IEEE 802.3af/at |
| Working Environment | Operating Temperature : -20°C~55°C, Storage Temperature : -20°C~75°C, Operating Humidity : 10%~95%, non-condensing |
| Certification | CE Mark, Commercial CE/LVD EN60950, RoHS |
| Radiation | CE Mark, Commercial FCC Part 15 Class B VCCI Class B EN 55022 (CISPR 22), Class B |
| Transmission Distance |
100 meters
|
| Power Supply Type | PoE Default Power Supply Is End-Span (1/2, 3/6 Line Pair), Alternative PoE Power Supply Is Mid-Span (4/5, 7/8 Line Pair) |
| Product Size | 118*89*25mm |
| Weight | 0.24kg |
| Warranty | 3 Month |
What In the Box
- 1 x POE31004P 4 + 1 port 10/100 Mbps 65W Ethernet PoE Switch - Powered IP Camera
- 1 x Power Adapter
- 2 x Mouting Kits
- 1 x User Guide
Warranty
3 Months Warranty
Local Manufacturer Warranty
Warranty Policy:Please complete and submit Product Warranty Registration Form within 14 days of purchase to ensure continuous coverage.
