D-Link AX3000 Mesh Gigabit Wi-Fi 6 Router (DIR-X3000Z)

D-Link AX3000 Mesh Gigabit Wi-Fi 6 Router (DIR-X3000Z)

Standards

• Wi-Fi 6

• IEEE 802.11ax/ac/n/a 5 GHz

• IEEE 802.11ax/n/b/g 2.4 GHz

Wi-Fi Speeds

• AX3000

• 5 GHz: 2402 Mbps (802.11ax 160Mhz)

• 2.4 GHz: 574 Mbps (802.11ax 40Mhz)

Wi-Fi Range

• Bedroom Houses

• 5 * Fixed High Performance Antennas

• Multiple antennas form a signal boosting array to cover more directions and large areas

• Beamforming

• Concentrates wireless signal strength towards clients to expand Wi-Fi range~ • High Power FEM

• Improves transmission power to strengthen signal coverage

Wi-Fi Transmission Power

• CE:<20dBm (2.4GHz); <23dBm (5.15GHz~5.35GHz); <30dBm (5.47GHz~5.725GHz)

• FCC:<30dBm (2.4GHz &5.15GHz~5.25GHz&5.725GHz~5.825GHz)

Modes

• Router Mode, Access Point Mode

Processor

• 1G Arm9 Dual Core CPU

Ethernet Ports

• 1 × Gigabit WAN Port

• 3 × Gigabit LAN Ports

Connectors & Buttons

• Power On/Off, WPS, Reset Button

Power

• 12V 1.5A DCWi-Fi

Encryption

• WPA, WPA2, WPA3

Network Security

• SPI Firewall

• Access Control

• IP & MAC Binding

• Application Layer Gateway

• DDoS Attack Prevention

Guest Network

• 1 × 5 GHz Guest Network

• 1 × 2.4 GHz Guest Network

Protocols

• IPv4, IPv6WAN Types• DHCP, Static IP, PPPoE

Easy Mesh

• Easy Mesh™ Supported

• Coverage your whole home with 3 x Devices

NAT Forwarding

• Port Forwarding, DMZ, UPnP

IPTV

• IGMP Proxy, IGMP Snooping, Bridge, Tag VLAN

DHCP

• DHCP Client List, Server

DDNS

• DynDNS

Management

• Web based Configuration (HTTP)

• Remote Management

• Telnet Management

• TR069

• TR143

• TR181

• TR098

• Web Based Firmware Upgrade

• CWMP

• Diagnostic ToolsPackage Contents• Wi-Fi Router

• Power Adapter

• RJ45 Ethernet Cable

• Quick Installation Guide

System Requirements

• Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser

• Cable or DSL Modem (if needed)

• Subscription with an internet service provider (for internet access)

Certifications

• CE, FCC

Environment

• Operating Temperature: 0℃~40℃

• Storage Temperature: -40℃~70℃

• Operating Humidity: 10%~90% non-condensing

• Storage Humidity: 5%~90% non-condensing
