HIKVISION DS-7208HQHI-K1/E 8-Channel UP TP 4MP Turbo HD TVI AHD CVI CVBS IP CCTV 2WAY Audio DVR
Specification
| Video And Audio | |
| Image Sensor | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
| Audio Output | 1-ch, RCA (Linear, 1 KΩ) |
| Synchronous Playback | 8-ch |
| IP Video Input | 4-ch (up to 12-ch);Up to 6 MP resolution;Support H.265+/H.265/H.264+/H.264 IP cameras |
| HDTVI Input | 4 MP, 3 MP, 1080p25, 1080p30, 720p25, 720p30 *: The 3 MP signal input is only available for channel 1 of DS-7204HQHI-K1, for channel 1/2 of DS-7208HQHI-K1, and for channel 1/2/3/4 of DS-7216HQHI-K1. |
| HDCVI Input | 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| CVBS Input | PAL/NTSC |
| Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
| Analog Video Input | 8-ch;BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| AHD Input | 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| CVBS Output | N/A |
| HDMI/VGA Output | HDMI:1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz HDMI and VGA simultaneous output VGA:1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Network | |
| Network Protocols | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| Remote Connections | 64 |
| Network Interface | 1, RJ45 10M/100M self-adaptive Ethernet interface |
| Auxiliary Interface | |
| Capacity | Up to 10 TB capacity for each disk |
| Serial Interface | N/A |
| USB Interface | 2 × USB 2.0 |
| Alarm In/Out | N/A |
| SATA | 1 SATA interface |
| Recording | |
| Encoding Resolution | Main stream: When 1080p Lite mode not enabled: For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps For 1080p stream access: 1080p/720p@15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode enabled: 4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) Sub-stream: WD1/4CIF@12fps; CIF@25fps (P)/30fps (N) |
| Video Bit Rate | 32 Kbps to 6 Mbps |
| Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| Dual Stream | Support |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711u |
| Audio Bit Rate | 64 Kbps |
| General | |
| Consumption(Without HDD) | ≤ 9 W |
| Working Humidity | 10% to 90% |
| Power Supply | 12 VDC |
| Working Temperature | -10 °C to +55 °C (+14 °F to +131 °F) |
| Dimensions(W × D × H) | 265 × 225 × 48 mm (10.4 × 8.9 × 1.9 inch) |
| Weights (Without HDD) | ≤ 1.6 kg (3.5 lb) |
What's in the box
- 1 x HIKVISION DS-7208HQHI-K1/E 8-Channel UP TP 4MP Turbo HD TVI AHD CVI CVBS IP CCTV 2WAY Audio DVR
- 1 x Power Adaptor
- 1 x Mouse
- 1 x Sata Cable
- 1 x Hard Disc Power Cable
- 1 x User Manual
- 1 x Screw Sets
Warranty
1 Years Warranty
Local Manufacturer Warranty
Warranty Policy:Please complete and submit Product Warranty Registration Form within 14 days of purchase to ensure continuous coverage.LAZADA Warranty Registration http://LWR.accessglobal.info Email us at Service@accessglobal.com
